GDSPLOT/W converts GDSII files into a raster plot format suitable for large format color or monochrome plotters. The program does all raster calculations on the workstation - the plotter's CPU and memory is not used at all. With a powerful workstation even very large chips can be plotted quickly.

GDSPLOT handles very large files by subdividing the job internally into a series of smaller strips depending on the workstation's available RAM memory. Each portion of the page that is plotted is called a "band." The band size is determined by the overall page width and the amount of RAM available to store raster data for that band.

• Plots very large GDSII files over 2 GB.
• Very Fast - uses bitmapped replication of SREF/AREF Data.
• Supports Hierarchical GDSII data.
• Easy to Use Step-by-Step User Interface
• Set Layer Colors, 4 lineweights - 1,2,3,4 pixels thick. Keeps your
  text from disappearing in a sea of boundaries.
• Fill Patterns and Boundary Linetypes.
• Plot selected structure and layers.
• Plot Selected Window or extents of data.
• Supports text and text scaling.
• Custom Fill Pattern File.
• Special Contact Fill Patterns.
• Includes Powerful GDSII Viewer - GDSVU.
• Available in Floating or Node Locked Version.
• Supports Plotters and Printers from HP and other major manufacturers.

• Supports up to 1,024 layers of GDSII.

• Supports up to 4096 vertices per boundary.

• HP Design Jets - 250/350/500/650/750/800/1050/5000 and others.

• HP Desk Jets - 550C/660C/820C/1600C
• HP Laser Jets - Series III, IV, V
• Calcomp Inkjets - Techjet Family
• Encad - NovaJet Pro (36 and 50 inch)
• Selex
• OCE
• PostScript Level II Compatible Devices

• Pentium or equivelent CPU
• 128 Mbytes of RAM
• Windows
