GDSPLOT is a fast and easy-to-use program for making large color plots of today's complex chips. GDSPLOT handles multi-gigabyte stream files on powerful UNIX and Window's workstations.

Because it rasterizes the data on your workstation, your plotter runs at full speed - no waiting for the plotter to convert HPGL or Postscript into its native format.

Whether you design your chips with Cadence, Mentor, Avanti, Synopsis or Tanner, GDSPLOT is the ideal companion for plotting.

See what our customers have to say about GDSPLOT when compared head-to-head against the competition!. Over 1,000 users, large and small, have licensed GDSPLOT in the last 5 years!.
