ASM 600 for Unix is a bidirectional translator between GDSII stream and Gerber. It is useful for generating photoplot artwork from IC layout tools that read and write GDSII such as Cadence's Virtuoso, Avanti's Apollo, Tanner's LEDIT, Design Workshop 2000 and others.


Applications

IC packages

Chemical milling masks

Hybrid circuits

MultiChip Modules

Microwave MMICs and MICs


Features

  • Menu Driven

  • Multi-aperture Area Fill

  • MDA POEX or RS274X G36/G37

  • GDSII Viewer - (XGDSVU)

  • Gerber Viewer - (XGBRVU)



  • Platform Requirements

    Solaris 2.51 or later HPUX 10.2 or 11




    Data Sheet Download Revision History Price
